磁粉制動器當前位置：首頁 > 磁粉制動器
- 水冷式磁粉制動器（TJ-POD-Y） 品牌：臺灣天機
型號：TJ-POD-Y
扭矩：2.5Nm~20000Nm
電壓：DC24V
包裝：紙箱+泡沫
類型：水冷式磁粉制動器（剎車器）
訂購熱線：13316607853
商品介紹
（天機傳動）水冷式磁粉剎車器（TJ-POD-Y），單出軸、止口支撐、水冷磁粉制動器，額定轉矩：100-20000N.m，額定電壓：DC24V。適用于放卷張力控制 磁粉制動器，還經常被用于傳動機械的測功加載和制動等。
水冷式磁粉制動器（剎車器）工作時能輸出較大的制動力矩和滑差功率，運轉時需通水冷卻，一般配備一套自動水循環系統，以保證磁粉制動器工作時產生的熱量與水交換帶出散發掉。
水冷式磁粉制動器（剎車器）的冷卻方式有兩種，具體冷卻方式和注意事項如下：
1、水泵實時供水冷卻：水泵電動機質量好的可選擇此類冷卻方式；
2、蓄水虹吸自然冷卻：此裝置由蓄水箱、電磁閥、儲水箱、水泵及磁粉制動器構成，優點是在水泵損壞后仍可供水冷卻；
操作上還需要時刻注意，開機時應先開水泵冷卻電機，以保證磁粉制動器正常運轉，提高運轉壽命。
天機牌水冷式磁粉制動器（TJ-POD-Y）的安裝尺寸和具體參數如下：
